A polyline can draw the points you give it. It cannot discover the road between them.
What is Codename One? Codename One is an open-source framework for building native iOS, Android, desktop, and web apps from a single Java or Kotlin codebase. Learn more at codenameone.com.
PR #5480 adds com.codename1.maps.routing, a portable route model and service layer for road geometry, distance, duration, waypoints, alternatives, legs, steps, and encoded polylines.
We talked about routing in Friday's release post.
The two-line route
For the common case, give Routing a map and two coordinates:
MapView map = new MapView();
Routing.showRoute(
map,
new LatLng(38.8977, -77.0365),
new LatLng(38.8894, -77.0352)
);
The call returns immediately. The routing service finds the best route, the API adds its polyline, and the map frames the result.
showRoute(...) is intentionally small. It is useful when the line itself is the result. An application that needs error UI, custom styling, ETA, or alternatives should use the callback route.
Own the result when it matters
RouteRequest request = new RouteRequest(origin, destination)
.setTravelMode(TravelMode.DRIVING)
.addWaypoint(coffeeStop)
.setAlternatives(true)
.setSteps(true);
Routing.findRoute(request, new RouteCallback() {
public void routesFound(List routes) {
Route best = (Route) routes.get(0);
map.addPolyline(best.toPolyline()
.setStrokeColor(0xff5722)
.setStrokeWidth(6));
map.fitBounds(best.getBounds(), 40);
distanceLabel.setText(
Math.round(best.getDistanceMeters() / 1000.0) + " km");
etaLabel.setText(
Math.round(best.getDurationSeconds() / 60.0) + " min");
}
public void routeFailed(String message, Throwable error) {
ToastBar.showErrorMessage(message);
}
});
The callback is invoked exactly once and always later on the Codename One EDT, even if a custom service responds synchronously, responds from a worker thread, responds twice, or throws after responding. The facade contains those service errors so application timing does not depend on the provider implementation.
The model exposes:
One or more route alternatives
Total distance and duration
Geographic bounds
Route geometry
Legs between waypoints
Step instructions and maneuver locations
Provider metadata
PolylineCodec supports precision 5 and precision 6 encoded geometry. That lets a service retain the compact wire format and decode it only when a Polyline is needed.
OSRM makes the first run easy
The default RouteService is OsrmRouteService. It needs no API key, so the two-line example can work without provider signup.
That default points to the public OSRM demonstration server. The server has no production SLA and asks clients to keep usage light. It can reject large or abusive workloads, and its public profile is configured for cars.
This means:
DRIVING is appropriate for a quick test.
WALKING or CYCLING against the default demo can still return car routing.
A shipping application should use a provider and capacity it controls.
Offline routing requires another implementation.
Travel mode is a request, not a guarantee. A RouteService reports what it supports, and an application should not label a result “walking” when the active backend only has a car graph.
Point OSRM at infrastructure you control
OSRM is open source and can be self-hosted. If your server exposes an OSRM-compatible route endpoint, install it as the application service:
Routing.setService(new OsrmRouteService(
"https://routing.example.com"
));
Use the exact constructor and endpoint configuration supported by your selected release. The architectural point is that application code still consumes Route, not provider JSON.
For a different provider, implement RouteService:
public final class CompanyRouteService implements RouteService {
public String getId() {
return "company-routing";
}
public boolean isAvailable() {
return credentialsAreReady();
}
public void findRoutes(RouteRequest request, RouteCallback callback) {
// Translate the portable request, call the provider,
// then return portable Route objects through the callback.
}
}
Routing.setService(new CompanyRouteService());
That seam supports commercial providers, a company gateway, an offline engine, or a route service with domain constraints such as truck height and hazardous materials.
The maps API and routing API stay separate
MapSurface displays geometry. RouteService discovers geometry. Keeping them separate avoids tying a route provider to one renderer.
The same route can be:
Drawn on a native or vector map
Styled according to traffic or accessibility
Summarized as distance and ETA
Saved as an encoded polyline
Compared with alternatives
Sent to another screen without retaining the map component
The API does not yet claim turn-by-turn navigation, rerouting, traffic prediction, offline map packages, or voice guidance. Those are stateful products with location updates and provider-specific rules. This release provides the route result that those systems need, without naming a static polyline “navigation.”
Production checklist
Before shipping:
Choose a routing service with terms, capacity, data coverage, and travel profiles that fit the application.
Report route failures to the user. The no-callback showRoute(...) convenience method cannot do that.
Verify units before displaying them. The model uses meters and seconds.
Test dateline crossing, unreachable points, ferries, tolls, and waypoint order for the markets you serve.
Keep provider keys out of client code when the provider expects a server-side secret.
Attribute map and routing data according to each provider's license.
A route is an answer from a changing road graph, not a decorative line. The new API finally represents it that way.
Next in the series: why Codename One is starting a staged move beyond Maven Central.
